Problem
A highly instructive problem in Software Performance Engineering: multiply two square matrices of a given size.
Naive Python Implementation
For now we’ll say N = 1024. Let’s start with a very naive Python implementation to get a sense of the problem:
import random
from time import *
N = 1024
A = [[random.random() for _ in range(N)] for _ in range(N)]
B = [[random.random() for _ in range(N)] for _ in range(N)]
C = [[0] * N] * N
start = time()
for i in range(N):
for j in range(N):
for k in range(N):
C[i][j] += A[i][k] * B[k][j]
end = time()
print(f"Time taken: {end - start}")
On my machine this took ~3 minutes. Likely not acceptable for most use cases.
Naive Rust Implementation
Now let’s try the exact same naive algorithm, but in Rust (using the dev/unoptimized build):
fn main() {
let A = random_array();
let B = random_array();
let mut C = [[0.0; N]; N];
let start = Instant::now();
for i in 0..N {
for j in 0..N {
for k in 0..N {
C[i][j] += A[i][k] * B[k][j]
}
}
}
let duration = start.elapsed();
println!("Time taken: {:?}", duration);
}
This finished in 12 seconds on my machine - for a whopping 15x increase against the same Python implementation!
Modifying Loop Order
Now for something maybe not so obvious. Let’s consider the following loop order change:
fn main() {
let A = random_array();
let B = random_array();
let mut C = [[0.0; N]; N];
let start = Instant::now();
for i in 0..N {
for k in 0..N {
for j in 0..N {
C[i][j] += A[i][k] * B[k][j]
}
}
}
let duration = start.elapsed();
println!("Time taken: {:?}", duration);
}
This code finishes in about 7 seconds for me. All I did was swap the loop order from i-j-k to i-k-j and we achieved a nearly 50% speedup! Let’s look at all of the possible loop orders and their running time:
| Loop Order | Running Time |
| ----------- | ------------ |
| i-j-k | 11.8s |
| i-k-j | 7.6s |
| j-i-k | 10.1s |
| j-k-i | 21.8s |
| k-i-j | 7.7s |
| k-j-i | 21.4s |
Why the speedup?
This difference in running time is caused by how well the loop order takes advantage of the CPU cache (specifically, it’s spatial locality). If we examine the number of cache misses between the best and worst loop order, we find that for the worst loop order we have ~18.5M LL cache misses:
valgrind --tool=cachegrind ./target/debug/matrix
...
LL misses: 18,489,921 ( 18,094,045 rd + 395,876 wr)
...
but for the best loop order, we only have ~800k LL cache misses:
valgrind --tool=cachegrind ./target/debug/matrix
...
LL misses: 795,759 ( 399,883 rd + 395,876 wr)
...
The loop order which better takes advantage of the matrix memory layout will perform better.
Compiler Optimization
Notice in the previous section that the binary lives in the target/debug directory. Which means I’ve been compiling the “dev” version this whole time. Let’s see how well the “release” version performs:
cargo r --release
...
Finished release [optimized] target(s) in 0.01s
Running `target/release/matrix`
Time taken: 328.815344ms
That is incredible 🤯! It’s hard to understate how amazing that is. We went from a Python prototype running on the order of minutes, to a binary running on the order of milliseconds - mostly by just passing a single flag to the Rust compiler. This should always be the first trick to reach for. Let’s increase the matrix size to further push our machines.
1024 -> 4096
As promised previously, lets increase the matrix size to 4096 and look at how our algorithm performs now:
cargo r --release
Compiling matrix v0.1.0 (/home/caden/matrix-optimizations/matrix)
Finished release [optimized] target(s) in 0.24s
Running `target/release/matrix`
Time taken: 28.704995681s
Ouch - that’s much, much worse.
Parallel Loops
Okay, what’s everyone’s first instinct when wanting to optimize something? Parallelize the work! Why only utilize a single core of the machine when we have multiple? Where could we apply parallelization? A very natural candidate would be the loops:
for i in 0..N {
for k in 0..N {
for j in 0..N {
C[i][j] += A[i][k] * B[k][j]
}
}
}
Parallel loops in Rust?
Introducing rayon - a highly regarded data-parallelism crate for converting sequential computations into parallel ones. Adding rayon to my Cargo.toml:
[dependencies]
rayon = "1.7.0"
Which loop?
A good rule of thumb for parallelizing loops is start with the outer loop first. We can easily keep the code structure the exact same and simply drop in a single par_iter_mut on the outer loop:
C.par_iter_mut().enumerate().for_each(|(i, row)| {
for k in 0..N {
for j in 0..N {
row += A[i][k] * B[k][j]
}
}
}
After running:
Time taken: 6.75999719s
we see a fantastic 4x speedup! Applying the same technique to the k-loop:
C.par_iter_mut().enumerate().for_each(|(i, row)| {
row.par_iter_mut().enumerate().for_each(|(k, val)|
for j in 0..N {
*val += A[i][k] * B[k][j]
}
}
}
we get a significant 33% speedup: Time taken: 4.749579936s!
As as sanity check, I confirmed that all 16 of my cores were being utilized though monitoring the core usage with htop.
What’s the speed limit?
Thus far, we’ve blindly tried optimization techniques with no sense of what an optimal solution really is. Time for a bit of math. Consider the following specs for my machine and let’s calculate it’s maximum possible number of FLOPS:
| Feature | Specification |
| ------------------------ | ------------- |
| Clock frequency | 2.9GHz |
| Processors | 2 |
| Cores / Processor | 8 |
| Float instrs. / Cycle | 16 |
Max flops = (3.3 x 10^9) x 2 x 8 x 16 = 845 GFLOPS
Now that we know what the hard limit of our machine, how far away from the limit are we?
2n^3 = 2(2^12)^3 = 2^37 floating-point operations
Running time = 4.75s
=> Flops = 2^37 / 4.75 = 29 GFLOPS
=> Utilization = Flops / Max flops = 29 / 845 = 3.4%
We’ve only achieved 3.4% of the maximum😕. That really makes you appreciate the engineering work behind hyper-optimized libraries such as numpy:
import random
import numpy as np
from time import *
N = 4096
A = np.array([[random.random() for _ in range(N)] for _ in range(N)])
B = np.array([[random.random() for _ in range(N)] for _ in range(N)])
start = time()
C = np.matmul(A, B)
end = time()
print(f"Time taken: {end - start}")
Time taken: 0.5340592861175537
What’s next?
Well, we clearly have a lot to improve on. To name just a few directions we could travel down for further speedups:
Each of these adventures could be their own blog posts, so for the sake of brevity lets call it a day here, and feel happy about the speedups we were able to achieve.
